Debugging Linux Start-Up Speed Performance Issues
Today while LearningLinux I noticed that
my ArchLinux VMs started as fast as always, but it seemed to take longer and longer for sshd to be ready.
This clarified what was happening:
$ systemd-analyze
Startup finished in 1.270s (kernel) + 42.586s (userspace) = 43.857s
graphical.target reached after 42.585s in userspace.
$ systemd-analyze blame
41.769s pacman-init.service
29.292s reflector-init.service
1.198s systemd-networkd-wait-online.service
601ms dev-vda2.device
393ms ldconfig.service
360ms sshdgenkeys.service
234ms systemd-networkd.service
168ms systemd-tmpfiles-setup.service
155ms systemd-timesyncd.service
145ms systemd-resolved.service
102ms systemd-udev-trigger.service
94ms systemd-logind.service
93ms systemd-udevd.service
82ms systemd-machine-id-commit.service
79ms systemd-journal-catalog-update.service
69ms user@1000.service
54ms systemd-tmpfiles-setup-dev.service
43ms systemd-journald.service
42ms systemd-journal-flush.service
37ms systemd-tmpfiles-clean.service
37ms sys-kernel-tracing.mount
36ms kmod-static-nodes.service
36ms dev-mqueue.mount
36ms modprobe@configfs.service
36ms sys-kernel-debug.mount
36ms modprobe@drm.service
35ms dbus.service
35ms modprobe@fuse.service
35ms dev-hugepages.mount
$ systemd-analyze critical-chain
The time when unit became active or started is printed after the "@" character.
The time the unit took to start is printed after the "+" character.
graphical.target @42.585s
└─multi-user.target @42.585s
└─sshd.service @42.585s
└─pacman-init.service @814ms +41.769s
└─basic.target @811ms
└─sockets.target @811ms
└─dbus.socket @810ms
└─sysinit.target @805ms
└─systemd-update-done.service @798ms +5ms
└─ldconfig.service @404ms +393ms
└─local-fs.target @402ms
└─run-user-1000.mount @20.308s
└─local-fs-pre.target @402ms
└─systemd-tmpfiles-setup-dev.service @346ms +54ms
└─systemd-sysusers.service @314ms +30ms
└─systemd-firstboot.service @293ms +20ms
└─systemd-remount-fs.service @258ms +29ms
└─systemd-journald.socket @242ms
└─-.mount @237ms
└─-.slice @237ms
Huh, so critical-chain shows that sshd was blocked by pacman-init… we can see that from the Before=sshd.service here:
$ cat /etc/systemd/system/pacman-init.service
[Unit]
Description=Initializes Pacman keyring
Before=sshd.service cloud-final.service
ConditionFirstBoot=yes
[Service]
Type=oneshot
RemainAfterExit=yes
ExecStart=/usr/bin/pacman-key --init
ExecStart=/usr/bin/pacman-key --populate
[Install]
WantedBy=multi-user.target
Why is pacman-init THAT (42s!) slow?
$ sudo systemctl status pacman-init
● pacman-init.service - Initializes Pacman keyring
Loaded: loaded (/etc/systemd/system/pacman-init.service; enabled; preset: disabled)
Active: active (exited) since Fri 2022-09-09 21:17:26 UTC; 54min ago
Process: 294 ExecStart=/usr/bin/pacman-key --init (code=exited, status=0/SUCCESS)
Process: 348 ExecStart=/usr/bin/pacman-key --populate (code=exited, status=0/SUCCESS)
Main PID: 348 (code=exited, status=0/SUCCESS)
Tasks: 1 (limit: 2322)
Memory: 7.9M
CPU: 40.283s
CGroup: /system.slice/pacman-init.service
└─332 gpg-agent --homedir /etc/pacman.d/gnupg --use-standard-socket --daemon
Sep 09 21:16:51 archlinux pacman-key[521]: gpg: setting ownertrust to 4
Sep 09 21:16:51 archlinux pacman-key[348]: ==> Disabling revoked keys in keyring...
Sep 09 21:17:25 archlinux pacman-key[348]: -> Disabled 52 keys.
Sep 09 21:17:25 archlinux pacman-key[348]: ==> Updating trust database...
Sep 09 21:17:25 archlinux pacman-key[694]: gpg: marginals needed: 3 completes needed: 1 trust model: pgp
Sep 09 21:17:25 archlinux pacman-key[694]: gpg: depth: 0 valid: 1 signed: 6 trust: 0-, 0q, 0n, 0m, 0f, 1u
Sep 09 21:17:26 archlinux pacman-key[694]: gpg: depth: 1 valid: 6 signed: 93 trust: 0-, 0q, 0n, 6m, 0f, 0u
Sep 09 21:17:26 archlinux pacman-key[694]: gpg: depth: 2 valid: 73 signed: 28 trust: 73-, 0q, 0n, 0m, 0f, 0u
Sep 09 21:17:26 archlinux pacman-key[694]: gpg: next trustdb check due at 2022-11-16
Sep 09 21:17:26 archlinux systemd[1]: Finished Initializes Pacman keyring.
Note how it apparently took it 31s to disable 52 revoked keys in keyring". That seems like a long time?
Note how the earlier systemd-analyze blame also mentioned reflector-init.service taking 29s… it also blocks sshd:
$ cat /etc/systemd/system/reflector-init.service
[Unit]
Description=Initializes mirrors for the VM
After=network-online.target
Wants=network-online.target
Before=sshd.service cloud-final.service
ConditionFirstBoot=yes
[Service]
Type=oneshot
RemainAfterExit=yes
ExecStart=reflector --latest 20 --protocol https --sort rate --save /etc/pacman.d/mirrorlist
[Install]
WantedBy=multi-user.target
Why is reflector THAT (31s!) slow? We can actually easily reproduce it manually without systemd:
[arch@archlinux ~]$ time reflector --latest 20 --protocol https --sort rate
[2022-09-09 23:21:29] WARNING: failed to rate http(s) download (https://archmirror.it/repos/community/os/x86_64/community.db): HTTP Error 403: Forbidden
[2022-09-09 23:21:29] WARNING: failed to rate http(s) download (https://mirror.cyberbits.asia/archlinux/community/os/x86_64/community.db): <urlopen error [Errno 101] Network is unreachable>
################################################################################
################# Arch Linux mirrorlist generated by Reflector #################
################################################################################
# With: reflector --latest 20 --protocol https --sort rate
# When: 2022-09-09 23:21:32 UTC
# From: https://archlinux.org/mirrors/status/json/
# Retrieved: 2022-09-09 23:21:02 UTC
# Last Check: 2022-09-09 23:17:25 UTC
Server = https://mirror.osbeck.com/archlinux/$repo/os/$arch
Server = https://mirror.pseudoform.org/$repo/os/$arch
Server = https://mirror.selfnet.de/archlinux/$repo/os/$arch
Server = https://ftp.halifax.rwth-aachen.de/archlinux/$repo/os/$arch
Server = https://archlinux.mirror.luzea.de/$repo/os/$arch
Server = https://mirror.cyberbits.eu/archlinux/$repo/os/$arch
Server = https://europe.mirror.pkgbuild.com/$repo/os/$arch
Server = https://geo.mirror.pkgbuild.com/$repo/os/$arch
Server = https://archlinux.mailtunnel.eu/$repo/os/$arch
Server = https://archlinux.thaller.ws/$repo/os/$arch
Server = https://mirror.theo546.fr/archlinux/$repo/os/$arch
Server = https://arch.mirror.constant.com/$repo/os/$arch
Server = https://america.mirror.pkgbuild.com/$repo/os/$arch
Server = https://asia.mirror.pkgbuild.com/$repo/os/$arch
Server = https://sydney.mirror.pkgbuild.com/$repo/os/$arch
Server = https://seoul.mirror.pkgbuild.com/$repo/os/$arch
Server = https://phinau.de/arch/$repo/os/$arch
Server = https://archlinux-br.com.br/archlinux/$repo/os/$arch
Server = https://archmirror.it/repos/$repo/os/$arch
Server = https://mirror.cyberbits.asia/archlinux/$repo/os/$arch
real 0m30.372s
user 0m0.886s
sys 0m0.418s
I’m not sure how expected this is. I’m pretty sure it was much faster for me just yesterday - as in just a few seconds, not 40s. Perhaps this is a temporary situation due to problems with some ArchLinux mirrors. IMHO it would be great if that wouldn’t slow down start-up of new Arch VMs.
I have created this ArchLinux bug for further discussion about this.
